| Item | Spec. | Remarks | |
| Frequency Range | 1100-1500 MHz | Bandwidth Range±10MHz | |
| Working Voltage | 28V | 28V | |
| Working current | ≤ 9A | output 100W | |
| Sweeping speed | 220 KHz | Can customize 100-500KHz | |
| Digital Lora | MCU |
Pseudo random interference / LORA |
|
| Output Power (Max) | 50±1 dBm | 100W | |
| Gain (Max) | 50±1 dB | ||
| Ripple in Band | ≤ 4 dB | Peak | |
| Bandwidth adjustment | Yes | By screw | |
| Center adjustment | Yes | By screw | |
| Enable control | Customize | 3-28V | |
| Input power (Max) | ≤ +10dBm | Optional (If signal source from Subscriber) | |
| Input Signal Source | Built-in high-speed noise modulation signal source |
Optional (can customize VCO, DDS or SDR) |
|
| Output VSWR | ≤2.0 |
Inside circulator, VSWR protect |
|
|
|
Working Temperature |
-20～+65℃ |
Working properly |
|
Gain Stability |
±1 dB |
at -20℃～+65℃ |
|
|
Power stability |
±1 dB |
at -20℃～+65℃ |
|
|
Power supply Port |
Positive and negative lines |
28V GND; (optional: Enable control wire) |
|
|
Shell Material |
Aluminum with natural color oxide sand blasting | ||
|
Vibration Need |
Meet the load need of moving vehicle | ||
|
RF output connecto |
N-Female | ||
|
LED indicator light |
Power ON/OFF | ||
|
Dimension |
150*80*22mm | ||
|
Installation Dimension |
144.3*74*22 mm | ||
|
Screw Size |
M2.0 | ||
|
Weight |
800g | ||
