GW-UAV102P8 High Power 8 band 1.2 km jamming range anti drone gun

Item No.: GW-UAV102P8
GW-UAV102P8 High Power 8 band 1.2 km jamming range anti drone gun
Description
Description

8 Band UAV Counter 433MHz 900MHz WiFi 2.4G 5.2G 5.8G GPSL1 UAV Signal Jammer

Portable light UAV Drone Jammer, Built-in high gain directional antenna, Built-in 8 sets of independently operated RF working unit, can choose to on/off GPS to drive the drone or force the drone to land, can be transmitted shielding interference signals to the surrounding 45-degree angle, Coverage (500-1200m) can be comprehensive and stable uninterrupted shielding of the 433MHz,900MHz,GPSL1-L5,WIFI 2.4G/5.2G/5.8G bands in the UAV frequency band.

Product Description

Applications:

Sensitive Areas

Prisons

Oil Refineries

Military Bases

Protected Areas



Function:
Effective interference with UAV 433Mhz 2400MHz, GPSL1-L5 5800MHz,5200MHz 900MHz.



Parameter

Channel

Working Frequency

Output power(±1dBm)

CH1

2.4G

2400-2500MHz

46 dBm (40W)

CH2

5.2G

5150-5300MHz

45 dBm (30W)

CH3

5.8G

5700-5900MHz

45 dBm (30W)

CH4

1.2G

1150-1300MHz(GPS)

41 dBm (10W)

CH5

1.4G

1430-1520MHz

41 dBm (10W)

CH6

1.5G

1570-1620MHZ(GPS)

45 dBm (30W)

CH7

433MHz

428-438MHz

41 dBm (10W)

CH8

900MHz

840-960MHz

41 dBm (10W)

Power supply mode

Inside battery: 28V, 8Ah;

Battery working time

30-40 minutes

Working temperature

-20ºC to +55ºC

Power consumption

340W

Weight

7.3KG, Packing Weight:18KG

Size

853X370X240mm

Directional Antenna

13dBi Gain

Total output power

170W
